2mm Thickness Galvanized Steel Vehicle Barrier Gate With LED screen
Product Introduction
Barrier Gate with LED screen is a luxury model, specially designed
to meet users with high requirements. The LED screen is in the
middle of the barrier housing. With a specified software and data
wire, you can input the detailed time information like, 20:00,
Friday, June 30th 2013. And you can input any words you like, in English and Chinese.
This barrier gate also has traffic light indication. Green and Red
light remind people whether it can be transited or forbidden to
transit.
Specification
| Model | WSTP-134 |
| Working Temperature | -40℃～+75℃ |
| Voltage | 220V±10%, 110V±10%, 50/60HZ |
| Rated power | 80W |
| Relative humidity | ≤90% |
| Remote control distance | ≥30m |
| Gross weight | 64kgs |
| Speed | 1S. 3S, 6S |
| Max boom length | 8 meters |
Advantages
Barrier Gate with LED screen uses the first generation motor. It is
stable and has long service life performance, running more than
five million times. Its housing is made of galvanized steel with
2mm thickness, and painted, so that the barrier can be used in door
and outdoor.
The barrier core is special and main parts are aluminum alloy
casting. The barrier gate will automatically reverse when the boom
meets the obstruction. The barrier works well with infrared
photocells, loop detectors, the boom will automatically rise up
when it meets pedestrian and vehicles. The clutch of the barrier
gate is fixed inside the housing, which can be easily rotate
manually with any clutch key; Meanwhile, the exclusive balance
device makes the barrier gate work more safely and conveniently.
Functions
1. Manual release device to operate the barrier when power failure
2. Barrier motor with die-casting aluminum alloy is high-hermetic
and easy for heat dissipation
3. Motor cooling fan to avoid the over-heating possibility
4. Automatic reversing when the barrier boom meets the obstruction
5. Auto closing realization through menu setting on the control
panel
6. The barrier works well with infrared photocells, loop detectors,
card readers, ticket dispensers, manual switch (wire control), and
traffic light
7. RS485 Communication Module is compatible
8. Traffic light interface
9. LED Screen
10. Automatic moisture control
11. Infrared Photocells (optional)
12. Support the external and internal Vehicle Loop Detector
(optional)
What we offer?
1.One-stop procurement service is available.
2.Quickest delivery and best aftersales service.
3.Veteran technician solves all your problems.
4.Passionate and professional sales makes a wonderful team.
5.Competitive and reasonable price with high quality products and
advanced technology.
6.Providing the most professional solution as soon as possible
according to your requirements.
