1: power failure automatic gate, no clutch design,
Incoming call automatic reset, restore to close state. If you have
special need that manual intervention, it can be set up easily, you
can gently rotate poles to manual Open / close boom without open
the housing by using adjust the control board
2: a variety of input and output modes can be selected, often open
and close can be selected.
3: rod angle can be adjusted from 55~90 degrees, 10 degree
resolution.
4: Closing speed can be adjusted, 0.9s, 1.3s, 1.8s.
5:all kinds of state signal output.
6: barrier gate running state OK signal output.
7: alarm signal output.
8: traffic lights signal relay output.
9: external Vehicle detection signal, infrared sensor signal.
10: AC90V~AC264V50/60Hz, the global universal voltage standard.
Also available
24V battery power supply.(No mains place to pick up solar
energy,wind energy to recharge battery)
11: the Opening time is less than 0.9s.
12: the running noise is less than 60dB.
13: standard file length 3m.
14: Power consumption: 50W, maximum power 100W.
15:It is also a simple matter to change the handing on-site from
right-axial to left-axial.
16: automatically detect whether the balance spring fatigue or
damage, if the spring
fatigue tips to adjust, if you can not adjust the spring, replace
the spring is very easy,
no need to use tools, hand can be replaced.
17: remote control open / close and car park system control open /
close, separate
input, respectively, the number of corresponding statistics.
18: the RS232 or RS485 connected to PC of the parking system.
RFQ:
Q: What's the order process?
A: Follow the steps on below to complete your order.
- 1. Inquiry
Provide us detailed information about your requirement, and we'll
recommend the suitable products according to your request
-2. Quotation
Official quotation form with all clear specifications according to
the order
-3. Invoice
Invoice will be issued once the quotation is confirmed.
-4. Payment
Payment shall be issued once the invoice issued. Full payment is
acquired.
-5. Production
Bulk production shall be taking 15-25 working days.
-6. Delivery
by sea, air or courier. Detailed picture of package will be
provided upon the service you've chosen. Packaging info will be
sent upon confirmation.
