Run Speed Adjustable Inverter Motor Intelligent Barrier For Car Parking Lot

Quick Details:

Working temperature(motor): -35℃~+85℃

Working temperature(control panel): -35℃~+85℃

Voltage:220V±10%,50HZ or 110V±10%,60HZ

Rated Power:80W,capacitor:9+uF/450W

Humidity:≤90%RH

Distance of remote control:100M＞L≥30M in the open place

Common Malfunctions and Solutions

1 The arm is no reaction when connect the power and press the open/close key.
a: Check the controller’s power supply and fuse.
b. There is no battery or power shortage on the remote control, the distance is too far.
c.There is co-frequency interference in the vicinity, check with the wire control interface to see if it’s normal.
d.The external protection circuit has failed or in a protected state,check the infrared device or loop detector device.
e:Check the motor and capacitor to see if invalid.
2 The boom could not raise up or fall down when press the open/close key.
a:The photoelectric limit is on bad contact,check the connections.
b:Replace the photoelectric limit switch.
3 The motor is buzz,boom is no reaction when press the open/close key.
a:The voltage is insufficient,check the 220V power supply.
b:The gears are stuck, and hand wheel rotates several circles toward the loose place, and re-adjust the photoelectric
limit to prevent the struck caused by mechanical limit from being before the photoelectric limit.
c:It’s imbalance between the balance spring and boom,re-adjust it.
4 The boom is not horizontal and vertical.
a:The photoelectric limit is shaft,re-adjust and fix.
b:Check the connection rod and adjust the boom to horizontal and vertical,and make the photoelectric
limit acts before the mechanical limit.
5 The force for arm up become smaller,sometimes need the handle assistance to make it up.
a:Check the motor and capacitor.
b:Re-adjust the spring balance.


Functions and Features:

1.Arm direction can be quickly interchanged
2. Run speed can adjust from 0.9sec to 6sec, 4sec lift max 6m arm.
3.Arm automaticlly locking when power off, then open the barrier gate by motor wheel
4.Remote control to operate the barrier gate.
5.Auto-reverse when the boom meets obstruction.
6.Infrared photocells connector is available.
7.Loop detector connector is available.
8.Well-intergrated with car parking system equipment,with wire control(must be switch signal).
9.Connector for traffic light(AC220V,power less than 40W)
10.Offering dry contact signal for car parking system(COM,NC,NO)
11.Auto-delay when closing(adjustable)

Service Items

1 One year’s free servicing is supplied(not including the arm);
2 Lifetime charged servicing is offered;
3 Technology servicing is supplied.
The following situations are charged for servicing(or changing):
1) Broken by the wrong installation.
2) Broken by improper voltage.
3) The surfaces of the system destroyed by wrong installation or use.
4) Broken by natural disaster.
5) Overdue.
6) Servicing items out of our promises.

FAQ:

Q: Are you trading company or manufacturer ?
A: We are a professional barrier gate manufacturer.
Q: How long is your delivery time?
A: Generally it is 2-5 days if the goods are in stock. or it is 5-7 days if the goods are not in stock, it is according to quantity.
We can send it for you by DHL/Fedex/TNT/SEA/AIR or your requirments.
Q: How about payment terms our company provide?
A: T/T or Western Union.
Q: Do you provide samples ?
A:No,we don't provide samples. The MOQ of our products is 1pc.
