New Inverter Motor Vehicle Barrier Gate With Run Speed Adjustment
1. Variable frequency controller product description
Barrier Gate controller -- variable frequency type, is the enhanced
barrier control which speed can be adjusted .
Adopting full remote control mode, with the open /stop/close wire
control interface ,counting interface, special
encoder limit interface, loop detector interface, infrared
interface, open limit,close limit output interface,
communication interface.The remote control code is the learning
code,and receiver module adopts external
superheterodyne reception.
2. Product Series and Parameter
| Boom type | Boom Length (L) | Operation time(S) | Height between boom and ground(M) |
| Straight boom | 6M ≥L>5M | 6S | H=0.83M |
| 5M≥L≥4.5M | 6S |
| 4.5M>L≥3M | 6S |
| 90 degree folding boom | L≤5M | 6S |
| 180 degree folding boom | L≤5M | 6S |
| Two fe nce boom | 5M≥L≥4M | 6S | H=0.9M |
| 4M>L≥3M | 6S |
| Three fence boom | 5M≥L≥4M | 6S | H=1.5M |
| 4M>L≥3M | 6S |
3. Functions and Features
3.1.The arm direction can be quickly interchanged
3.2.Open the barrier gate by motor wheel when power off and
automatic locking when power on.
3.3.Balance boom running with a motor transmission of cranks and
shafts.
3.4.Remote control to operate the barrier gate.
3.5.Auto-reverse when the boom meets obstruction.
3.6.Infrared photocells connector is available.
3.7.Loop detector connector is available.
3.8.Well-intergrated with car parking system equipment,with wire
control(must be switch signal).
3.9.Connector for traffic light(AC220V,power less than 40W)
3.10.Offering dry contact signal for car parking system(COM,NC,NO)
3.11.Auto-delay when closing(adjustable)
4. Technical Data
4.1 Working temperature(motor): -35℃~+85℃
4.2 Working temperature(control panel): -35℃~+85℃
4.3 Voltage:220V±10%,50HZ or 110V±10%,60HZ
4.4 Rated Power:80W,capacitor:9+uF/450W
4.5 Humidity:≤90%RH
4.6 Distance of remote control:100M＞L≥30M in the open place
Service:
Service for free:
1. One year free service is supplied(not including the arm and
remote)
2. Lifetime charged service is supplied
3. Technical service is supplied
4. OEM: we can customized machine case, color, logo for you, which
accroding to your detailed requirements.
5. Technical support and aftersales service, it is a long term
relatioship between us.
6. Price can be negotiable when you have big order quantity.
Service for charging:
1. Broken by wrong installation
2. Broken by improper voltage
3. The surfaces of the barrier destroyed by wrong installation and
usage
4. Overdue service items are out of our promise.
FAQ:
Q: Are you trading company or manufacturer ?
A: We are a professional barrier gate manufacturer.
Q: How long is your delivery time?
A: Generally it is 2-5 days if the goods are in stock. or it is 5-7
days if the goods are not in stock, it is according to quantity.
We can send it for you by DHL/Fedex/TNT/SEA/AIR or your
requirments.
Q: How about payment terms our company provide?
A: T/T or Western Union.
Q: Do you provide samples ?
A:No,we don't provide samples. The MOQ of our products is 1pc.
