Long Range RFID Reader For Gate Motor Intelligent Barrier Gate
WONSUN SUMMER PROMOTION: BUY 20 SETS, GET 1 FOR FREE
IF INTEREST, PLEASE CONTACT ME FREELY
SKYPE: zimin1314
Whatsapp: +86 18507481610
Quick details:
1) Beam length: <=6m
2) Opening (Closing) time: 1s, 1.8s,3s, 6s
3) Machine core working temperature: -40 degrees to +75 degrees
4) Electric working temperature: -20 degrees to +75 degrees
5) Rated voltage: AC 220V (10%) 50Hz/60Hz, 110V (10%) 50Hz/60Hz
6) Rated power: 120W
7) Relative humidity: <=90%
8) Remote control distance: <=30m
9) Net weight: 55KGS
10) Package size: 1025*375*470mm
Features as follows:
1) The top of cover is square and it looks elegant.
2) Machine core with compression spring, effectively avoids the
accidents caused by spring breaking
3) Die-casting aluminum alloy motor, precision and good at thermal
radiating
4) Torque motor,steady,low noise,long life
5) This barrier gate provides optional case color as
yellow/orange/white/red/blue
6) This automatic barrier gate provides optional boom arm direction
as leftward/rightward
7) This type of barrier could match with direct boom( pole) , fold
boom or fence boom.
Functions:
1) Manual release
2) Machine core with compression spring, effectively avoids the
accidents caused by spring breaking
3) Die-casting aluminum alloy motor, precision and good at thermal
radiating
4) Motor cooling fan, solving the problem of heat-protection
5) Double safety limit switches (photocell electrical limit
switch/motor memory sensor)
6) Reversing on obstacle,Auto-closing
7) Support the INFRARER PHTOCELL for anti-bumping function
(optional)
8) Support the external and internal VEHICLE LOOP DETECTOR
(optional)
9) Traffic light interface
10) Wire control (switch signal)/ Remote control (418MHZ)
11) RS485 communication module (optional)
Each barrier gate will include:
1 pcs Gate Barrier
1 pcs arm boom (from 1m to 6m can customised)
1 pcs control panel(built inside)
2 pcs remote controllers
1 pcs manual book
1 pair photocell( optional)
1 loop detector( optional)
1 RS485( optional)
Service items
1.One year's free servicing is supplied( not including the arm)
2. Lifetiom charged servicing is offered.
3. Technology servicing is supplied
The following situations are charged for servicing (or changing):
1. Broken by wrong installation.
2 Broken by improper voltae.
3. The surfaces of the system destroyed by wrong installation our
use.
4. Broken by natural disaster.
5. Overdue
6. Servicing items out of our promises.
The upgrade and improvement of the product won't be notified if
there is any.
The explaining authority of this product instruction and service
article belong to the production factory.
FAQ:
1. When barrier finish closing, why does the arm open itself
slowly?
- the spring is too tight, you need release the spring a little, then
test it again.
- see whether the main crank touch the triangle tightly or not, if
tightly, adjust it.
- reset the balance position and the electrical limit switch.
2. Why does the controller panel operate with "Di Di Di" abnormal
noises?
- As for this, it means the resistance on controller board is broken,
if you have professional tools to check,
- then replace that broken resistance, if not, replace that
controller panel.
3. Why does the barrier finish half operation of opening and
closing?
- If uses our controller panel, you only need to find resistance R37
on controller panel, and repalce it is ok.
4. When barrier closed, why is there a 5 degree angle of
inclination?
- the model is not good, and the gear doesn't fit each other tightly.
- the barrier didn't adjust well, need to reset.
5. When barrier finish open, but it closes itself without any order
control, what's the problem?
- To check the loop cable first, because the loop cable maybe brokem
- To check the motor sensor, if it is not set well, then reset it in
the middle between two holes on sensor rod.
