User-Friendly RFID Vehicle Parking Management System Card Read
distance
Quick Detail:
Housing material:Steel,Tempered glass
Color:orange / black / blue
IC card read/write time:≤0.2S
IC card read/write distance:≤10cm
Paper outing speed:≤2S
Mode of communication:Base RS-485, Rear TCP/IP
Communication transmission distance:1200m(RS-485)
Offline storage capacity:30000 pcs (extendible)
Card capacity:50000 pcs (extendible)
Functions & Features
1. Could run online, also support offline.
2. Could communicate in real-time with supervisory control computer
and other control device.
Could transfer payment info to supervisory computer realtime,
Supervisory computer could set the time and charge standard etc.
3. Could connect with automatic gate, and control the gate to open
when read a validity card.
4. Could set different cards, Value card,Temporary card and Month
card etc.
5. Show word: when read valid card, show how much need pay and
greeting; when read invalid card, show other relevant reasons.
6. Could talk to parking workers by intercom system nearby the exit
door.
Free for short-time parking: when the car parking is no more than
fixed time(like 10 minutes), it will be free.
Specifications
Housing Size | 1380H×460W×320D(mm) |
Housing material | Steel,Tempered glass |
Color | orange / black / blue |
IC card read/write time | ≤0.2S |
IC card read/write distance | ≤10cm |
Radio-frequency card read/write time | ≤0.2S |
Radio-frequency card read/write distance | ≤10cm |
Paper outing speed | ≤2S |
Mode of communication | Base RS-485, Rear TCP/IP |
Comunication transmission distance | 1200m(RS-485) |
Offline storage capacity | 30000 pcs (extendible) |
Card capacity | 50000 pcs (extendible) |
Blacklist capacity | 10000 pcs (extendible) |
Data transmission speed | 4800bps/100M |
Working Temperature | minors 30°C to 70 °C |
Working environments | indoor,outdoor |
Relative humidity | ≤95% coagulation free |
