Heavy Duty Customizable drop arm gate for Airport, AC230V 60Hz
Barrier Gate Operator
Barrier Gate Operator Applications:
Highway
Airport
Bus station
Supermarket
Army
And other places with heavy traffic flow
Barrier Gate Operator Specifications:
| Barrier Gate Operator Supply Voltage | AC230V or AC110V |
| Barrier Gate Operator Power Frequency | 50/60Hz |
| Barrier Gate Operator Rated Power | 100 W |
| Barrier Gate Operator Rated Speed | 10r/min |
| Barrier Gate Operator Rated Torque | 30N. m |
| Barrier Gate Operator Standard Lever Length | <=5.0m straight lever |
| Barrier Gate Operator Noise | <=60dB |
| Barrier Gate Operator Rising/Falling Time | 3.2s |
| Barrier Gate Operator Service Life | more than 5 million times |
| Barrier Gate Operator Error action | <=0.01% |
Barrier Gate Operator Functions And Features.
1. This Boom Barrier Gate Operator is widely used for the facilities of parking, traffic, or toll
systems.
2. Barrier Gate Operator Arms can be chosen from 3 meters to 6 meters.
3. Barrier Gate Operator Machine core with compression spring, effectively avoids the
accidents caused by spring breaking
4. Die-casting aluminum alloy motor, precision and good at thermal
radiating
5. Bidirectional self-locking function.
6. Time protection function.
7. The "Barrier Gate Operator open" command has high priority.
8."Close" command memory function available.
9. Barrier Gate Operator Remote control interface, Remote control emitter can be equipped.
10. Three operation modes: Remote control, push button, manual
operation.
11. Loop detector can be equipped.
Communication with customers
1. The Barrier Gate Operator motor works but there is no reaction on the arm.
a. Please check whether the clutch device is locked or not.
2. There is too much vibrant when the boom is rising or falling.
a. Please check whether the shock absorption rubber is broken or
not, if yes, change a new one.
b. Please check whether the balance spring is overused and
distorted. If yes, change a new one.
b. Please check whether the balance spring is overused and
distorted. If yes, change a new one, or spin
the bottom adjust nut.
3. The Barrier Gate Operator boom could not rise or fall to the end.
a. When changing a long boom to a short one, please readjust it.
b. The sensor does not plug well, please check it.
c. The " Speed adjust switch" is wrong adjust, please readjust it.
4. The distance of the remote control decreases.
a. Check whether the charge capacity of the remote controller is
enough or not.
5. There is no reaction when pressing the remote controller
buttons.
A, Please check whether the power is supplied to the Barrier Gate Operator or not.
b. Please check whether the fuse is burnt out or not.
c. Please check whether the code both in the remote controller and
the control board are accordant or not.
6 There is no reaction on the motor when the user changes a control
board.
a. Please check whether the capacitance is correctly fixed or not.
b. Please check whether the sensor is right inserted or not.
