Wonsun Commercial Advertising Durable Smart Parking Barrier Gate
With High Quality
Introduction
We are a professional car park barrier gate manufacture, which
established at 2010, with more than 12 years experience of
researching and developing barrier gate, we have nearly 1200sqm
workshop for 4 zones, about 30 experienced and skilled workers,
daily production of 60 sets boom barrier gate. We are committed to providing more stable, more practical and
environmentally friendly parking barrier gate for the customers who
are in the field of the access control system.
Parameter
Working Temperature: -30℃~+70℃
Power Supply: DC24V
Open/close Speed: 4Sec-8Ｓec
Rated Power: 250W
Driving Method； DC Brushless Motor
Output Power:78.8N.m
Remote Control Distance:≤100m(open,sunny weather)
Protection Grade: IP54
Motor No - load Speed:1850r/min
Max Boom Length:4.5m
Advantage
Features
1. The operation speed can be adjusted(4sec to 8sec).
2. Arm direction can be quickly interchanged.
3. Barrier gate up &down signal relay switch output.
4. R&G Traffic light relay switch signal output.
5. External loop detector signal anti-smashing interface.
6. Infrared sensor signal anti-smashing interface.
7. Count mode interface.
8. Arm swing out function, when vehicle hit the
barrier gate,the arm can be swing out to avoid further
damage on the vehicle and barrier machine core.
9. High-sensitivity arm auto reverse function
(intensity can be adjusted).
10. Parking system interface.
11. RS485 communication interface.
12. Power off the backup battery interface.
13.Automatic arm lift function when power off (need to add power
storage module).
