Two Speed Range 1.2s DC Brushless Traffic Barrier Gate With RS485
Folding Arm
1. Parameters of Barrier Arm Type,Length and Operation Speed
| Arm Type | Arm length(L) | Open/ close speed | Center height H |
| Straight arm | 6m≤L＜5m | 5S | H=0.83m,Height of arm center from ground |
| 5m≤L＜4.5m | 4S |
| 4.5m≤L＜3m | 3S |
| 3m≤L＜2.5m | 1.2S |
| 90°Folding arm | L≥5m | 5S |
| 180°Folding arm | L≥5m | 5S |
| Two fence arm | 4.5m≤L≤4m | 6S | H=0.9m,Height of arm center from ground |
| 4m≤L≤3m | 3S |
| Three fence arm | 4m≤L≤3.5m | 6S | H=1.5m,Height of arm center from ground |
2. Features
2.1 The running speed can be adjusted from 3s to 8s
2.2 Can be quickly interchanged
2.3 Open the barrier gate by motor wheel when power off
,automatically reset after power on
2.4 Curved crank arm three- link movement structure, the operation
is stable
2.5 Wireless remote control control open/close
2.6 Auto reverse function(force adjustable)
2.7 Infrared photocells connector is available
2.8 Loop detector connector is available.
2.9 Well-integrated with car parking system equipment,with wire
control(must be switch signal)
3. Technical parameters
| Working temperature(motor): -30℃~+70℃ |
| Rated voltage:DC24V |
| Running speed:1.2s~4s/ 3s~8s |
| Rated current:8.58A |
| Rated power:160W |
| Remote control distance:≤100M(in the open place) |
| IP Degree:IP44 |
| Max length of arm:6M |
Barrier arm balance adjustment
1,Please check and confirm arm status in horizon and vertical
position,then tighten 2pcs M12 screw.
2,According to arm balance status, repeat adjusting the spring
level of tightness of M8*140MM, make
sure the arm open and close in stable.
3,For the barrier gate with double springs,please adjust the two
springs simultaneously.
4,If arm open and close shake too much, Please check below picture.
Open arm shaking a lot means
spring is too tight, loose a little. Close arm shaking too much
means spring too lose, repeat tighten a little spring.
FAQ
1-Can you install using loop detector or pressure sensor on it?
Yes,the stanadard advertising barrier gate have loop detector and
pressure sensor.
2-How about the guarantee and after sale service?
We have 1 year quality guarantee, We own well tranied and passional
sales & aftersale services who can speak fluent English language.
3-How long is the leading time?
For standard item
10-50 sets:5 working days
50-100 sets:7-10 working days
200-500 sets:10-15 working days
For special item, or need custom design package or logo, need 3-10
working days longer.
4-How about the payment terms?
TT,western union,our company already joined the trade assurance,it
will highly protect your order security.
5-How do you send the products to me,how long?
As our products are big volume,and heavy duty, we suggest you to
ship by sea. You can also choose your own shipping
forwarder. it normally takes 7-60 days depend on different
countries.
6-What is the package of the barrier gate?
Inside with a carton package.Then outside,there are wooden crate
package.
