    Speed Adjustable Traffic Barrier Gate 24V DC Brushless Motor Car Park Barrier With 6m Arm

    Ask Lasest Price
    Brand Name : WONSUN
    Model Number : DZ-132
    Certification : CE
    Price : $269/Set
    Payment Terms : L/C, T/T, Western Union
    Supply Ability : 3000 Set/Sets per Month
    Delivery Time : 5-8 work day
    • Product Details
    • Company Profile

    Speed Adjustable Traffic Barrier Gate 24V DC Brushless Motor Car Park Barrier With 6m Arm

    Speed Adjustable Traffic Barrier Gate 24V DC Brushless Motor Car Park Barrier with 6m Arm


    product description

    Model No.DZ-132 Parking Barrier Gate
    Framework MaterialCold-roll sheet
    BeamAluminum alloy
    Dimension343 * 300 * 1001mm
    Net Weight48KG
    Input InterfacePhoto cell, loop detector, parking system,wire control
    Input12V relay signal or Pulse Wide>100MS
    Power SupplyDC24V/AC110V/220V,50/60HZ
    Motor Consumption160W
    Working Temperature-35°C to +85°C
    Relative Humidity≥90%
    MCBF5million time
    Push ButtonSupport
    Remote ControlTwo button remote transmitter, Distance≤100m
    Optional AccessoriesLoop detector; IR photo cell
    Beam Length3M - 6M
    Opening/Close Time

    1.5sec~6sec


    Functions and Features:

    1 The running speed can be adjusted from 1.5s to 6s

    2 Arm direction can be quickly interchanged

    3 Barrier gate up and down signal relay switch output

    4 R&G Traffic light relay switch signal output

    5 External loop detector signal anti-smashing interface

    6 Infrared sensor signal anti-smashing interface

    7 Count mode interface

    8 Arm swing out function,when the vehicle hit the barrier

    9 High-sensitivity arm auto reverse function (intensity can be adjusted)

    10 Parking system interface

    11 RS485 communication interface

    12 The back up battery interface

    13 Automatic Arm lift function when power off(need to add power storage module)


    Speed Adjustable Traffic Barrier Gate 24V DC Brushless Motor Car Park Barrier With 6m ArmSpeed Adjustable Traffic Barrier Gate 24V DC Brushless Motor Car Park Barrier With 6m ArmSpeed Adjustable Traffic Barrier Gate 24V DC Brushless Motor Car Park Barrier With 6m ArmSpeed Adjustable Traffic Barrier Gate 24V DC Brushless Motor Car Park Barrier With 6m ArmSpeed Adjustable Traffic Barrier Gate 24V DC Brushless Motor Car Park Barrier With 6m Arm


    Our Services

    Service for free:
    1. One year free service is supplied(not including the arm and remote)

    2. Lifetime charged service is supplied

    3. Technical service is supplied

    4. OEM: we can customized machine case, color, logo for you, which accroding to your detailed requirements.

    5. Technical support and aftersales service, it is a long term relatioship between us.

    6. Price can be negotiable when you have big order quantity.


    Service for charging:

    1. Broken by wrong installation

    2. Broken by improper voltage

    3. The surfaces of the barrier destroyed by wrong installation and usage

    4. Overdue service items are out of our promise.


    FAQ

    Q: Are you trading company or manufacturer ?
    A: We are a professional barrier gate manufacturer, indusrty and trade integration.
    Q: How long is your delivery time?
    A: Generally it is 2-5 days if the goods are in stock. or it is 5-7 days if the goods are not in stock, it is according to quantity.

    We can send it for you by DHL/Fedex/TNT/SEA/AIR or your requirments.
    Q: How about payment terms our company provide?
    A: T/T or Western Union or
    Q: Do you provide samples ?
    A:No,we don't provide free samples. The MOQ of our products is 1pc.
